Dry Wet Separated Closed Cooling Tower
Dej txias ntws: 50-2,000 m³ / h
Qhov Loj (Min): 2.6 m × 5.7 m × 3.8 m
Dimensions (Max): 13 m × 26 m × 9.5 m
Ntxuam Dia: 1.8-12 m
Lub zog kiv cua: 6-270 kW
Cua Flow Range: 68,851–2,950,000 m³ / h
Ntub qhuav thiab ntub dej sib cais tag nrho
Peb Cov Khoom Siv Hluav Taws Xob Cov Hluav Taws Xob Cov Hluav Taws Xob Hluav Taws Xob siv cov qauv tsim tshiab: ntu qhuav (finned hlab) thiab ntu ntub dej (coil nrog cov tshuaj tsuag) nyob rau hauv ib cheeb tsam sib cais thiab tsis txhob kov. Qhov no coj cov txiaj ntsig tseem ceeb. Nws yog tsim rau cov qauv AC daim ntawv thov (37℃hauv / 32℃tawm) nrog rau siab -kev ua haujlwm kub (85-60℃hauv / 45-35℃tawm). Dej ntws li ntawm 50 m³ / h txog 2,000 m³ / h. Lub pej thuam tso cai rau ib ntu kom muab kev pabcuam thaum lwm qhov txuas ntxiv ua haujlwm, yog li koj tsis tas yuav tsum nres tag nrho lub kaw lus. Cov fins qhuav nyob huv si vim tias cov tshuaj tsuag dej tsis tiv thaiv lawv. Rau cov chaw uas muaj dej tawv, qhov kev tsim no yog qhov kev daws teeb meem zoo tshaj plaws.
Ob Thaj Chaw, Zero Downtime, Zero Freeze Worry
Cov ntu qhuav ua haujlwm ua ntej-txias, txo cov load ntawm ntu ntub thiab txuag hluav taws xob. Cov kiv cua muaj qhov ntev ntawm 1.8 m txog 12 m hauv txoj kab uas hla, nrog lub zog ntawm 6 kW txog 270 kW, thiab cua ntws los ntawm 68,851 m³ / h mus txog 2,950,000 m³ / h. Lub Tsev Teev Ntuj Qhuav Separated Closed Cooling Tower tseem tiv thaiv kev tsim cov nplai, vim tias cov fins qhuav tsis raug rau cov dej txau-ib qho teeb meem tshwm sim hauv cov dej tawv. Lub suab nrov tau tswj hwm peb theem: ib txwm (64–78 dB(A)), qis (55–75 dB(A)), thiab qis qis (50–70 dB(A)), ua tau raws li qhov yuav tsum tau ua ntawm ib puag ncig thiab tso cai rau kev teeb tsa ze ntawm tsev lossis chaw ua haujlwm.
Kev tsim khoom niaj hnub thiab kev ntseeg thoob ntiaj teb
Peb lub Hoobkas tau nruab nrog cov tshuab siab heev, suav nrog cov plasma cutters, CNC brakes, thiab yob qub. Hauv xyoo 2024, peb tau ntxiv cuaj cov kab ntau lawm rau nws pib- tsim qhov chaw thiab cov hlau tsis muaj steel hlau, ua kom cov khoom zoo thiab cov ntim loj. Lub Tsev Teev Ntuj Qhuav Separated Closed Cooling Ntauwd nta ib lub kauj kauj thiab lub tshuab cua saum toj kawg nkaus, tso cai rau lub kauj kom ntws tawm hauv 3 feeb xwb- tiv thaiv kom tsis txhob khov thiab sib sau ua ke. Peb tau ua haujlwm tshaj 5,000 tus neeg siv khoom thoob ntiaj teb, suav nrog cov tuam txhab loj xws li Shandong Weiqiao, Xinjiang East Hope, thiab Inner Mongolia Huineng. Peb lub xub ntiag muaj zog hauv kev lag luam xws li Indonesia thiab Nyab Laj.
Khoom Specifications
|
Parameter |
Paub meej |
|
Dej Txias Dej |
50–2,000 m³/h |
|
Dimensions (Min) |
2.6 m × 5.7 m × 3.8 m |
|
Dimensions (Max) |
13 m × 26 m × 9.5 m |
|
Ntxuam Dia |
1.8–12 m |
|
Ntxuam Fais |
6-270 kW |
|
Cua Flow Range |
68,851–2,950,000 m³/h |
|
Txau lub zog |
3-27 kW × 2 |
|
Qhov hnyav ua haujlwm |
7,006–121,185 Kg |
|
Coil Test Siab |
1.5 MPa |
|
Cov khoom xaiv |
FRP, Stainless Hlau, Galvalume, Qhob |
FAQ
